Averaging Extensometers for ASTM D5656 Adhesive Lap Shear Tests – Model 4013

Designed specifically for performing tests in accordance with ASTM D5656, Standard Test Method for Thick-Adherend Metal Lap-Shear Joints for Determination of the Stress-Strain Behavior of Adhesives in Shear by Tension Loading. The deformation is measured on opposite sides of the test specimen and the output is an average of the two readings.

Epsilon extensometers are COMPATIBLE WITH VIRTUALLY EVERY BRAND OF TEST EQUIPMENT and can be supplied with the correct connector to plug in directly, or supplied with a separate conditioner and amplifier.

WITH EPSILON’S 20+ YEAR HISTORY OF SERVICE to the materials testing community, you know we will be there to stand behind our products when your critical application requires it.

36 EXTENSOMETER MODELS are available in many thousands of variations. Our focus on helping customers has led to the development of models to cover nearly any test method.

The Model 4013 extensometer meets the requirements of ASTM D5656 for measuring the strain properties of an adhesive in shear. It uses different contact point spacing compared to the extensometer shown in D5656. This makes it much easier to mount and eliminates the slippage problems associated with the design shown in D5656. The Model 4013 is available with all of Epsilon’s temperature configurations. It has a 3 mm (0.12 inches) full scale measuring range. The conical point contacts included with the extensometer are made from tungsten carbide.

The Model 4013 extensometers are strain gaged devices, making them compatible with any electronics designed for strain gaged transducers. Most often they are connected to a test machine controller. The signal conditioning electronics for the extensometer is typically included with the test machine controller or may often be added. In this case the extensometer is shipped with the proper connector and wiring to plug directly into the electronics. For systems lacking the required electronics, Epsilon can provide a variety of solutions, allowing the extensometer output to be connected to data acquisition boards, chart recorders or other equipment.

Download Data Sheet



  • High accuracy – strain is measured on opposite sides of the specimen and output as an average (single connector), or optionally as two independent readings (two connectors).
  • Meets the requirements of ASTM D5656.
  • Easy mounting, attaches with an integral spring.
  • Includes the Epsilon Shunt Calibration System for on-site electrical calibration.
  • Rugged, dual flexure design for improved performance.
  • Full bridge, 350 ohm strain gaged design for compatibility with nearly any test system.
  • Includes high quality foam lined case.

Download Data Sheet



Excitation: 5 to 10 VDC recommended, 12 VDC or VAC max.

Output: 2 to 4 mV/V, nominal, depending on model

Linearity: ≤0.2% of full scale measuring range

Temperature Range: Standard (-ST) is -40 °C to +100 °C (-40 °F to 210 °F)

Cable: Integral, ultra-flexible cable, 2.5 m (8 ft) standard

ce-certified



Download Data Sheet



  • Option for independent left and right measurement outputs (two connectors – requires two strain channels)
  • Connectors to interface to nearly any brand of test equipment

Download Data Sheet



Ordering Information

Click table options to configure

Measuring Range
extension #
0.5 mm -005M 005M
1.0 mm -010M 010M
3.0 mm -030M 030M
0.025 in -025T 025T
0.050 in -050T 050T
0.125 in -125T 125T
Temperature Range
degrees #
-270 °C to 100 °C (-454 °F to 210 °F) -LT LT
-40 °C to 100 °C (-40 °F to 210 °F) -ST ST
-40 °C to 150 °C (-40 °F to 300 °F) -HT1 HT1
-40 °C to 200 °C (-40 °F to 400 °F) -HT2 HT2
-270 °C to 200 °C (-454 °F to 400 °F) -LHT LHT
Model Number:  4013 – _ _ _ _ – _ _ _
Model Number:
4013 – _ _ _ _ – _ _ _
Model 4013 Available Versions: ANY combination of measuring range and temperature range listed above is available, except as noted.
Example: 4013-125T-LT: 0.125 inch measuring range, low temperature option (-270 °C to 100 °C)
